LED Area Light 300W/240W/200W 51000 Lumens UL, DLC Premium | 120-277V

SKU: AR09-300W-120V
$129.99 USD

Bulk Savings

automatically applied on carts over $500  - Learn more

  • Lumens : Up to 51,000lm
  • Voltage : AC120–277V
  • Wattage : 300W/240W/200W
  • Location: IP65
  • Dimming : Dimmable
  • Warranty : 5 years warranty
Read More
In stock
Usually ships within 24 hours
LED Area Light 300W/240W/200W 51000 Lumens UL, DLC Premium | 120-277V

120-277V

LED Area Light 300W / 240W / 200W 51000 Lumens UL, DLC Premium | 277-480V with Photocell Base

277-480V with Photocell Base

LED Area Light 300W / 240W / 200W 51000 Lumens UL, DLC Premium | 120-277V with Photocell Base

120-277V with Photocell Base

CCT Selectable

Got questions?

Feel free to get in touch

Ask an expert

Chat Email +1 (816) 2580438

Illuminate your space effortlessly!

Our lighting solutions are delivered with everything you need to set up easily. Unbox, install, and transform your home with brilliant light and style!

JCE AR09 LED Area Light delivers up to 51,000 lumens with selectable wattage and CCT in one fixture. Designed for parking lots and roadway applications, this DLC Premium certified fixture offers high efficacy, Type III distribution, and long-term reliability.

 Key Features

  • 300W / 240W / 200W Wattage Selectable

  • 3000K / 4000K / 5000K CCT Selectable

  • Max 51,000 Lumens

  • High Efficacy: 170 lm/W

  • Type III Light Distribution (T3)

  • 0-10V Dimmable

  • AC120-277V

  • 10KV Surge Protection

  • UL Listed

  • DLC Premium Qualified

  • IP65 Waterproof

  • 5-Year Warranty

 Technical Specifications

Specification Details
Model J-AR09-300/240/200W-L-PCX-3CCT-T3
Voltage 120-277V
Wattage 200W / 240W / 300W
Lumens 51,000 lm
Efficacy 170 lm/W
CCT 3000K / 4000K / 5000K
Distribution Type III
CRI >80
Dimming 0-10V
Surge Protection 10KV
IP Rating IP65
Housing Die-cast Aluminum
Lens Polycarbonate
Operating Temp -40°C to 50°C
Certification UL + DLC Premium
Warranty 5 Years

 Applications

Ideal for:

  • Parking Lots

  • Roadways

  • Commercial Outdoor Areas

  • Industrial Facilities

  • Security Lighting

Mounting Options (Sold Separately)

  • Slip Fitter (SF)

  • Direct Mount (DI)

  • Trunnion Mount (TR)

 Optional Accessories

  • Photocell (Dusk to Dawn)

  • Glare Shield

Order by 2PM to get delivered next working day! We use 24 hours service with carriers in most cases so that you can get your order delivered on time.

Additional charges will be imposed by our couriers for delivery to remote area, a surcharge may be levied to cover carriage to these areas.

Overview

Easy install with mount options for bright 21000lm area light. IP65 rated.



Specifications

Wattage 300W/240W/200W
LPW 170.0
Certifications UL Listed, DLC Premium
Lifetime Designed for long service life
Luminous Up to 51,000lm
Voltage AC120–277V
CRI 80
IP Rating IP65
Beam Angle Type III
Color Temperature Range 3000K / 4000K / 5000K (Selectable)
Mount type "3 kinds of mounting brackets available (SF, DI, TR) ·Plug-in and Zhaga socket microwave motion sensor available (Factory) Photocell dusk to dawn function Optional"
Applications Parking lots, Roadways, Outdoor applications
Efficacy per W 170lm/w
Operating Temperature -40°C-50°C
Dimming Details 0-10V
Size 20x11.8x2.0
Warranty 5 years warranty
