Upgrade your outdoor perimeter safety with JCE's commercial-grade LED mini wall pack lights. Featuring our advanced WP10 series with field-adjustable wattage (15W/20W/30W) and selectable 3CCT color temperatures (3000K/4000K/5000K), these compact outdoor fixtures deliver up to 3,900 lumens of reliable brightness. Equipped with dusk-to-dawn photocell readiness, they automatically manage nighttime illumination for enhanced facility security. Built with rugged weather-resistant housing and an IP65 waterproof rating, these commercial mini wall packs are ideal for entryways, pathways, residential perimeters, and smaller building facades. Fully certified and backed by our 5-year warranty with fast 24H shipping from US warehouses.
Multi-Wattage & 3CCT Specifications
| Selectable Wattage |
Lumen Output |
Color Temperatures (3CCT) |
Photocell Sensor |
Equivalent HID |
Ideal Applications |
| 15W Mode |
Approx. 1,950 lm |
3000K / 4000K / 5000K |
Dusk-to-Dawn Ready |
50W MH/HPS |
Residential Entryways, Porches |
| 20W Mode |
Approx. 2,600 lm |
70W MH/HPS |
Commercial Pathways, Side Doors |
| 30W Mode |
Approx. 3,900 lm |
100W MH/HPS |
Building Facades, Small Loading Docks |
Key Benefits of Field-Adjustable LED Mini Wall Packs
-
3-in-1 Stock Flexibility: Our WP10 Series Mini Wall Pack features an internal dip switch allowing you to toggle between 15W, 20W, and 30W on-site. This significantly reduces inventory overhead for contractors and distributors while ensuring you always have the right brightness handy.
-
Color Temperature Customization: Switch seamlessly between Warm White (3000K) for residential multi-family housing, Cool White (4000K) for professional offices, and Daylight (5000K) for high-security industrial areas.
-
Built-in Dusk-to-Dawn Photocell: No need to buy separate sensors or wire external controls. The integrated photocell option automatically activates the wall pack at sunset and turns it off at sunrise, boosting security while slashing utility bills.
-
Compact, Heavy-Duty Architecture: Housed in a compact, sleek die-cast aluminum frame with an impact-resistant polycarbonate lens, these mini wall packs offer maximum durability without the bulky appearance of standard commercial fixtures.
Frequently Asked Questions (FAQ)
Q: Where are the switches to change the wattage and color temperature (CCT)?
A: The adjustable slide switches are securely located inside the fixture housing to prevent tampering or weather exposure. Simply open the front cover using the side screws before installation to select your preferred settings.
Q: Can the photocell sensor be bypassed if I want to use a wall switch or timer?
A: Yes, absolutely. The integrated dusk-to-dawn photocell comes with a removable cap or can be easily disconnected inside the housing if your project requires manual switch control or central timer systems.
Q: What traditional commercial fixtures do these mini wall packs replace?
A: These compact energy-saving fixtures are perfect for replacing outdated 50W to 100W Metal Halide (MH) or High-Pressure Sodium (HPS) wall lights, cutting your power consumption by up to 80% while significantly lowering maintenance costs.
Q: Are these mini wall packs suitable for coastal or wet environments?
A: Yes. Our mini wall pack series is IP65 rated and wet-location certified. The premium die-cast aluminum enclosure features an anti-corrosion powder coat that withstands rain, humidity, and dusty outdoor conditions.
