LED UFO High Bay Light 150W 21000 Lumens ETL DLC Power Selectable | 277-480V

J-UFO12 LED UFO High Bay Light

Model: J-UFO12-150W/120W/100W-H

The J-UFO12 series LED High Bay is a professional-grade industrial lighting solution featuring dual switch selectable wattage and CCT. Designed with a die-cast aluminum housing and premium LED source, it delivers reliable high lumen output with excellent thermal performance.

🔧 Key Features

• Power Selectable: 100W / 120W / 150W

• Color Selectable: 3000K / 4000K / 5000K

• Input Voltage: 277–480VAC

• High Efficiency: Up to 140 lm/W

• CRI: >80

• Dimming: 0–10V dimmable

• LED Source: Lumileds

• Lens Type: 90° beam angle

• IK Rating: IK08 (PC lens)

• Certifications: ETL & DLC Listed

• Warranty: 5 Years

💡 Lumen Output

🏗 Construction

• Die-cast aluminum housing with powder coating finish

• UV stabilized polycarbonate lens

• Double switch design for wattage & CCT adjustment

• Plug & Play sensor compatibility (3-second install)

📐 Dimensions (150W Version)

• Diameter: 9.45" (Ø240mm)

• Height: 5.08"

• Weight: 5.7 lbs

• Packing: 1 pc / carton

🔩 Installation Options

• Hook Mount

• Yoke Bracket Mount

• Pipe Installation (Factory configuration G1/2 or G3/4)

🔌 Wiring

• Brown/Black: Line (L)

• Blue/White: Neutral (N)

• Green/Yellow: Ground (PE)

• Purple: DIM+

• Pink: DIM-

If you need photometric files (IES), layout assistance, or bulk pricing, contact us for technical support.
