LED Shoebox Area Light 150W 25500 Lumens 3CCT & Wattage Selectable UL ,DLC Premium | 120-277V

J-AR09 150W LED Shoebox Area Light

– 3CCT & Wattage Adjustable

Engineered for commercial parking lots, auto dealerships, industrial parks, and roadway applications, this 300W/240W/200W Wattage-Selectable LED Shoebox Area Light delivers ultra-bright, customizable site illumination with automated control capabilities. Generating up to 51,000 lumens at an incredible efficacy of 170 lm/W, this commercial-grade luminaire serves as an energy-efficient replacement for legacy 1,000W–1,500W metal halide or high-pressure sodium (HPS) fixtures. Outfitted with an integrated twist-lock photocell base (sensor included), it enables reliable dusk-to-dawn operation to optimize energy savings and maintain uninterrupted site security.

• Field-Selectable Wattage (300W / 240W / 200W): Conveniently tune light output on-site (up to 51,000 lumens) to match specific pole heights, coverage requirements, and project energy targets.

• Integrated Dusk-to-Dawn Photocell Base: Features a factory‑installed twist‑lock photocell receptacle. Photocell sensor sold separately to enable automatic nighttime turn‑on and daytime shutoff functionality.

• Universal Commercial Voltage (AC120–277V): Heavy-duty driver operates smoothly across standard 120V, 208V, 240V, and 277V power lines, featuring built-in surge protection against voltage spikes.

• DLC Premium & UL Listed: Meets top-tier performance standards to qualify for maximum commercial utility rebate incentives across North America; UL certified for wet locations.

• Rugged IP65 Weatherproof Housing: Built with heavy-duty die-cast aluminum and a corrosion-resistant powder-coated finish for optimal thermal heat dissipation and protection against rain, snow, and dust.

• Precision Type III Optics: Polycarbonate optical lenses deliver a wide, uniform beam distribution ideal for parking lots, driveways, and outdoor perimeter lighting.

• Smooth 0–10V Continuous Dimming: Compatible with standard 0–10V dimmers, occupancy sensors, or smart controls for custom energy management strategies.

• Versatile Mounting Adaptability: Supports flexible field mounting with options including Slip Fitter, Arm Mount for square or round poles, and Direct Wall Mount brackets.

Key Features

• Wattage Selectable: 100W / 120W / 150W

• 3CCT Adjustable: 3000K / 4000K / 5000K

• High Efficiency: Up to 170 lm/W

• Max Lumens: Up to 25,500 lumens

• Input Voltage: AC120-277V

• Light Distribution: Type III (T3)

• Dimming: 0-10V dimmable

• Surge Protection: 6KV

• Photocell: Dusk-to-dawn photocell included

• Waterproof Rating: IP65

• CRI: >80

• Operating Temperature: -40°C to 50°C

• Certification: UL & DLC Premium

• Warranty: 5-Year Limited Warranty

Construction

• Die-cast aluminum housing for superior heat dissipation

• Polycarbonate T3 lens for optimal light distribution

• Clamshell design for easy maintenance

Mounting Options (Sold Separately)

• Slip Fitter (SF)

• Direct Mount (DI)

• Trunnion Mount (TR)

Packaging & Weight

• Fixture Size: 19.1 x 11.1 x 4.5 inches

• Net Weight: 6.2 lbs

• Gross Weight: 7.3 lbs

• 1 unit per carton
