4FT LED Linear High Bay Light, 165W-300W Selectable, 50,400LM, 6CCT, 0-10V Dimmable, 120-277V, IP65, DLC Premium

4FT LED Linear High Bay Light with 165W-300W Selectable Power

Designed for high-output commercial and industrial lighting applications, this 4FT LED Linear High Bay Light combines five selectable wattage settings, six selectable color temperatures, high-efficiency LED performance, and standard 0-10V dimming in one versatile G1 series fixture.

The fixture can be field adjusted to 165W, 200W, 225W, 255W, or 300W, giving contractors, facility managers, and commercial lighting professionals greater flexibility when specifying lighting for warehouses, manufacturing facilities, distribution centers, gymnasiums, workshops, and other large high-ceiling spaces.

With luminous efficacy up to 168 lm/W, the fixture delivers up to 50,400 lumens at the maximum 300W setting. Six selectable color temperatures— 3000K, 3500K, 4000K, 5000K, 5700K, and 6500K— allow the light appearance to be adjusted during installation for different commercial and industrial environments.

Key Features

• 5-Level Wattage Selectable: Choose 165W, 200W, 225W, 255W, or 300W to match different lighting requirements, layouts, and installation conditions.
• Up to 50,400 Lumens: High-output illumination designed for large commercial, warehouse, and industrial spaces.
• Up to 168 lm/W: High luminous efficacy delivers strong light output while maintaining efficient power consumption.
• 6CCT Selectable: Select 3000K, 3500K, 4000K, 5000K, 5700K, or 6500K directly on the fixture.
• 0-10V Dimming Standard: Compatible with common commercial 0-10V lighting control systems for adjustable light output.
• 120-277V Universal Input: Designed for a wide range of North American commercial and industrial electrical systems.
• CRI 80: Provides reliable color rendering for warehouses, production areas, retail spaces, and general industrial use.
• 120° Wide Beam Angle: Provides broad light distribution across large floor areas, aisles, production zones, and open commercial spaces.
• IP65 Rated: Provides protection against dust and water ingress for demanding commercial and industrial environments.
• Durable Steel Construction: Built with 24-gauge steel housing and a powder-coated white finish for long-term commercial use.
• 50,000-Hour Rated Life: Designed to reduce maintenance requirements in commercial and industrial facilities.
• Wide Operating Temperature Range: Rated for operation from -4°F to 122°F.
• Flexible Mounting: Chain mounting is standard, with pendant and surface mounting options available for compatible installations.
• Optional Controls: Motion sensor and emergency battery backup options are available for project-specific requirements.
• Commercial Certifications: UL Listed, DLC Premium, FCC, and RoHS compliant.
• 5-Year Limited Warranty: Backed by a five-year limited warranty for commercial lighting projects.

High-Output 50,400-Lumen Performance

With output up to 50,400 lumens and efficacy up to 168 lm/W, this 4FT linear high bay is designed for applications requiring substantially higher illumination than lower-wattage commercial high bay fixtures.

The high-output design is particularly suitable for large open floor areas, manufacturing environments, distribution facilities, storage areas, and other high-ceiling spaces where strong and broadly distributed illumination is required.

Five Selectable Wattages in One Fixture

The integrated wattage selector allows installers to choose 165W, 200W, 225W, 255W, or 300W during installation. This helps one fixture platform accommodate multiple project requirements without specifying a separate fixed-wattage model for every lighting level.

*Reference outputs for lower wattage settings are calculated using efficacy up to 168 lm/W. Actual delivered lumen output may vary by configuration and operating conditions.

6CCT Selectable for Commercial & Industrial Projects

The integrated color temperature selector provides 3000K / 3500K / 4000K / 5000K / 5700K / 6500K in one fixture, allowing contractors to select the appropriate light appearance during installation.

• 3000K: Warm white illumination.
• 3500K: Warm-neutral commercial lighting.
• 4000K: Neutral white for commercial and industrial spaces.
• 5000K: Daylight white commonly used in warehouses and work areas.
• 5700K: Cool daylight for high-visibility environments.
• 6500K: Cool white for applications requiring a brighter visual appearance.

Wide 120° Light Distribution

The 120° beam angle and 4FT linear luminous surface provide broad light distribution across large spaces. This design helps illuminate aisles, production floors, storage areas, workshops, and open commercial environments with wide coverage.

Flexible Mounting Options

Chain mounting is standard for suspended high-bay installations. Pendant and surface mounting options are also available, allowing the fixture to accommodate different ceiling structures and commercial installation requirements.

Recommended Applications

• Large warehouses
• Distribution centers
• Manufacturing facilities
• Factories
• Production floors
• Industrial workshops
• Storage facilities
• Commercial garages
• Gymnasiums
• Retail and big-box stores
• High-ceiling commercial spaces

Technical Specifications

Frequently Asked Questions

What wattages can this 4FT LED linear high bay be set to?

The fixture provides five selectable wattage settings: 165W, 200W, 225W, 255W, and 300W.

How many lumens does the 300W linear high bay produce?

At the maximum 300W setting, the fixture delivers up to 50,400 lumens with luminous efficacy up to 168 lm/W.

What color temperatures are available?

Six selectable color temperatures are available: 3000K, 3500K, 4000K, 5000K, 5700K, and 6500K.

Is this LED linear high bay dimmable?

Yes. 0-10V dimming is standard for compatibility with common commercial lighting control systems.

What input voltage does this fixture support?

The fixture operates on 120-277V AC, 50/60Hz.

Is this 4FT LED linear high bay IP65 rated?

Yes. The fixture carries an IP65 rating for demanding commercial and industrial environments.

What mounting options are available?

Chain mounting is standard. Pendant and surface mounting options are also available for compatible installations.

Can a motion sensor be added?

Yes. A motion sensor is available as an optional configuration for projects requiring occupancy-based lighting control.

Is emergency battery backup available?

Yes. Emergency battery backup is available as an optional configuration for compatible commercial projects.

What certifications does this linear high bay have?

The fixture is UL Listed and DLC Premium qualified, and is also FCC and RoHS compliant.
